PCIe Gen3x4 M.2 2280 SSD





詳細規格 Specifications ...


Type LEVEN PCIe Gen3x4 M.2 2280 SSD
Model number JP500
Capacity 128GB,256GB,512GB,1TB
Dimension(LxWxH) 22 x 80 x 3.58 mm
Weight 8 g
Interface PCIe Gen3x4
Flash type 3D MLC NAND Flash
Controller SMI
Operation Temperature 0°C to 70°C
Storage Temperature -40°C - 85°C
Shock Resistance 1500G/0.5ms
Max. Performance Max. Read/Max. Write Speed: 2500/1100 MB/s
Max. 4K Read/Write IOPS up to 160K/140K
*Performance may differ depends on
the system configurations.
